CAN Digital Display Gauge

Overview

A high-performance CAN digital gauge designed to integrate directly with leading aftermarket ECUs. Built in a durable anodised 6061 aluminium housing, this unit delivers real-time engine data, advanced control features, fault monitoring, and full customisation — all in a compact 52mm form factor.

Whether you're tuning, racing, or building a serious street car, this display gives you complete visibility and control over your engine management system.

Key Features

• Anodised 6061 aluminium housing

• 46+ live CAN data channels

• Dual-point oscilloscope view

• Fault code monitoring and clearing!!

• ECM security access

• Fully adjustable warnings & shift light

• Adjustable units (PSI/Bar/kPa, °C/°F, KM/H/MPH)

• Dim display input & brightness control

• CAN output support

ECU Control Functions (ECM Dependent)

• Adjust boost level

• Adjust traction control

• Enable/disable antilag

• Enable/disable launch control

• Check engine light display

Display Screens

• Boost Gauge

• Dynamic Lambda Gauge

• Tachometer

• Multi-Gauge A, B & C

• User Defined Gauges (x2)

• Fault Code Monitor

• Live Data View (All Channels)

• Oscilloscope

• ECM Control

• Security & Settings

Supported ECUs

• Link Engine Management

• Haltech

• MaxxECU

• Emtron

• Ford Barra

• Hondata

• ECU Masters

• Motorsport Electronics UK

• Megasquirt

• Edelbrock

(Displays only data available from the connected ECU.)

Data Channels Available (ECU Dependent)

The gauge can display a wide range of live CAN data including:

• Boost / Manifold Pressure (with peak tracking)

• Lambda (multiple channels + overall)

• RPM

• Oil Pressure & Temperature

• Coolant Pressure & Temperature

• Fuel Pressure & Temperature

• Injector Duty Cycle & Pulse Width

• Ignition Timing

• Ethanol Content

• Throttle Position

• Gear Position

• Vehicle & Individual Wheel Speeds

• Cam Positions

• Exhaust Gas Temperatures (up to 8 channels)

• Battery Voltage

• ECU Temperature

• And more (46+ total parameters)

Fault codes can also be displayed directly on screen.

Installation & Wiring

Supplied with a pre-terminated 6-pin harness.
Requires 12V nominal DC with 0.5A fused supply.

Wiring:

• Black – Ground

• Red – Ignition 12V

• Orange – Dim Input

• Yellow – CAN High

• Green – CAN Low

• Brown – Not Used

Mounting

• 52mm body fits standard gauge holders

• 2x M3 threaded holes on rear (44mm centre-to-centre) for custom bracket mounting

CAN Setup (Example – Link ECU)

• Load supplied AIC CAN stream

• CAN ID: 1000

• Transmission Rate: 100Hz

• Enable CAN output in ECU software
